Description

TECHNICAL SPECIFICATION
Laser	Ytterbium Fiber Laser
Class	IV
Average Lase O/P Power	20 Watts
Wavelength	1060-1070 nm
Typical Beam Quality	M2 ≤ 1.4
Rd Pointer for Positioning	Visible Red Light (635 nm)
MARKING
Marking Speed	up to 7000 mm/sec
Marking Fields	110(std.)/155/215mm2 (Optional)
Work Clearance	185/296/387 mm
Min. Character Size	0.22mm
ELECTRICAL
Power Connection	220V 10 V AC, 1 Phase
Avg. Power consumption	< 1KVA
OTHER
Cooling Type	Air Cooled
Environment	Free from Dust, Oil, Mist & Other contaminations (incl. Structure)
Temperature	10-35°C
Max. Weight	< 140 Kg.
SOFTWARE
Windows 2000/Xp OS; .PLT, .DXF, .BMP, JPG Compatibility Bar Code, 2D Matrix, Serial Number Marking, Automation Support.

Note: Due to continues improvement, product specification may change without notice.
