Concrete Mixer Machine
Features:
• Chassis: Heavy Duty, Robust Steel Chassis from 125 X 65 mm Channel
• Batch Capacity: 10 Cu. Ft Unmixed / 7 Cu. Ft. Mixed.
• Power: 10 HP Air Cooled Diesel Engine / 10 HP, 3 Phase, 1440 RPM Electric Motor.
• Mixing Drum: Heavy Duty C.I.Drum, Tapper Bearing & Bushing with MS Blade for efficient Mixing. Drum Cone made from 4 mm M.S. Plate.
• Loading Hopper: Mechanical Hopper made from 3mm Plate.
• Wheels: Pneumatic Wheels (5 X 19) - 4 Nos.
• Jack Leveling: Pin Type 2 Nos.
• Column: Up to 50 ft.
• Drive: Frictional heavy bracket type
• Skip Unit: 0.3 cum with safety lock
• Wire Rope: 10mm Fiber Core (6 X 19 FMC)
• Chassis: Heavy Duty, Robust Steel Chassis from 125 X 65 mm Channel
• Batch Capacity: 10 Cu. Ft Unmixed / 7 Cu. Ft. Mixed.
• Power: 10 HP Air Cooled Diesel Engine with Pump / 10 HP Electric Motor Flange Mount with Pump - 1 Nos..
• Mixing Drum: Heavy Duty C.I.Drum, Tapper Bearing & Bushing with MS Blade for efficient Mixing. Drum Cone made from 4 mm M.S. Plate.
• Loading Hopper: Hydraulic Hopper made from 3mm Plate with Heavy Angle Structure Support for Hy. Cylinder.
• Hy. Oil Tank / Pipe: 15Ltr. Capacity / R2 Quality Hose Pipe.
• Wheels: Pneumatic Wheels (5 X 19) - 4 Nos.
• Jack Leveling: Pin Type - 2 Nos.
• Column: Up to 50 ft.
• Drive: Frictional Heavy bracket type
• Skip Unit: 0.3 cum with safety lock
• Wire Rope: 10mm Fiber Core (6 X 19 FMC)
Minimum Order Quantity: 1
1 Pack contains : 1 Unit
