Description

This new type of organic granulator is the best selling organic fertilizer granulator, which can be used in organic fertilizer granulation. It is with a larger production capacity to meet fertilizer investor’s needs.
The new granulation machine, using the high-speed rotary mechanical stirring force and the result aerodynamic force, makes fine powder be in continuous mixing, granulation, spheroidization and dense process in the machine, so as to achieve the purpose of granulation. Practical shape is spherical. Practical size is generally between 0.3-3mm. Granulation rate is ≥90%. The size of the particle diameter can be adjusted by the amount of mixing material and spindle speed. Under normal conditions, the lower the amount of mixing materials are add and the higher speed, the smaller the particles are, and vice versa. The finer the basic particles of the fine powder material, the higher the sphericality of the particles and the better ball quality. The qualified rate of the machine is as high as 80-90%, which is suitable for many different formulations. The ball rate is than 15%, and the uniformity of particle size can be adopted size can be adopted according to user’s requirement.

ITEM	QTY(SET)	SIZE
Plate	7	8M.M 1500X6300
Plate	2	6 M.M 1500X6300
10” Beam	2	35 Feet
10” Beam	2	5 Feet
6”X3” Channel	6	5 Feet
Guide Roole	4	Dia. 10”
Ring	2
Girari	1
Pinion	1
Gear 5” 30/1	1
Motor 15 HP 1440 RPM.	1
Plate	1	1500X2000 MM.
