The 7810 UV laser printer delivers high-contrast, permanent codes enabling product lifetime track and trace for pharmaceutical, medical device, and cosmetic manufacturers.
Power(W) | 2 W |
Laser Type | CO2 |
Automatic Grade | Automatic |
Beam Output | Steered beam |
Maximum Power | 2-Watt |
Laser Cooling | Air cooled |
Maximum Print Speed | 500 characters/sec |
Maximum Line Speed | 984 ft/min (300 m/min) |
Environmental Protection | Marking unit IP 20 /Supply unit IP 21 |
Laser Tube | Pulsed Nd YVO4 laser (Vanadat),diode-pumped |
Laser Source Expected Life | 15,000-25,000 hours |
Laser Wavelength Options | 355 nm |
Standard IO Connectivity | Ethernet |
Standard User Interface | Smart Graph (on optional external Windows 7 PC) |
Plant Air Used | No |
